Conversion efficiency
Module efficiency leading in industry, up to 21.7%
Engineering Drawing (MM )
Module efficiency leading in industry, up to 21.7%
Bifaciality is up to 70%, up to 25% more energy yield than conventional modules
Both side cell, symmetrical design, low risk of micro-crack
Half-cut cell technology provides optimized energy production under inter-row shading conditions
3-fold IEC new standard tests passed, 15-year material warranty, and 30-year power warranty
First choice of large power plants
Cell Type | P Type |
Module Size | 2278×1134×30mm |
Glass Thickness | 2.0mm |
Module Weight | 32.7Kg |
Output Cable | 4mm², cable length 300mm (can be customized) |
Connector | MC4 compatible |
Junction Box | IP68, 3 bypass diodes |
Frame | Anodized aluminium alloy |
Max. System Voltage | DC1500W |
Power Tolerance | 0~+5W |
Operating Temperatue | -40℃~+85℃ |
Max. Fuse Rated Current | 30A |
Front Static Load | Snow load 5400Pa, Wind load 2400Pa |
Packing Data | 36 pcs/Pallet；180(20GP)；720(40HQ) |
